Template class for transient simulator drivers. More...

#include <SIMSolver.h>

Inheritance diagram for SIMSolver< T1 >:

[legend]

Collaboration diagram for SIMSolver< T1 >:

[legend]

Public Member Functions
	SIMSolver (T1 &s1)
	The constructor initializes the reference to the actual solver.

virtual	~SIMSolver ()
	The destructor deletes the restart data handler.

virtual bool	read (const char *file)
	Reads solver data from the specified input file.

const TimeStep &	getTimePrm () const
	Returns a const reference to the time stepping information.

bool	advanceStep ()
	Advances the time step one step forward.

virtual int	solveProblem (char infile, const char heading=nullptr)
	Solves the problem up to the final time.

void	handleDataOutput (const std::string &hdf5file, const ProcessAdm &modelAdm, int saveInterval=1, int restartInterval=0)
	Handles application data output.

virtual bool	serialize (HDF5Restart::SerializeData &data)
	Serialize internal state for restarting purposes.

virtual bool	deSerialize (const HDF5Restart::SerializeData &data)
	Set internal state from a serialized state.

int	restart (const std::string &restartFile, int restartStep)
	Handles application restarts by reading a serialized solver state.

Public Member Functions inherited from SIMSolverStat< T1 >
	SIMSolverStat (T1 &s1, const char *head=nullptr)
	The constructor initializes the reference to the actual solver.

virtual	~SIMSolverStat ()
	The destructor deletes the results data exporter object.

void	handleDataOutput (const std::string &hdf5file, const ProcessAdm &modelAdm, int saveInterval=1)
	Handles application data output.

Public Member Functions inherited from SIMadmin
virtual	~SIMadmin ()
	Empty destructor.

virtual bool	preprocess (const IntVec &ignored={}, bool fixDup=false)
	Performs some pre-processing tasks on the FE model.

virtual bool	preprocessC (const IntVec &, bool, double=0.0)
	Performs some pre-processing tasks on the FE model.

const ProcessAdm &	getProcessAdm () const
	Returns the parallel process administrator.

int	getGlobalProcessID () const
	Returns the global process ID.

const std::string &	getHeading () const
	Returns the simulator heading.

void	setHeading (const std::string &heading)
	Defines the simulator heading.

void	printHeading (int &supStep) const
	Prints the heading of this simulator, if any, to IFEM::cout.

Public Member Functions inherited from XMLInputBase
bool	readXML (const char *fileName, bool verbose=true)
	Reads an XML input file.

bool	loadXML (const char *xml)
	Loads data from an XML-formatted text string.

Protected Member Functions
virtual bool	parse (char *keyw, std::istream &is)
	Parses a data section from an input stream.

virtual bool	parse (const tinyxml2::XMLElement *elem)
	Parses a data section from an XML element.

bool	saveState (int &geoBlk, int &nBlock, bool newMesh=false, char *infile=nullptr, bool saveRes=true)
	Saves geometry and results to VTF and HDF5 for current time step.

Protected Member Functions inherited from SIMSolverStat< T1 >
void	printHeading (const char *heading)
	Writes an application-specific heading, if provided.

Protected Member Functions inherited from SIMadmin
	SIMadmin (const char *heading=nullptr)
	The default constructor initializes the process administrator.

	SIMadmin (SIMadmin &anotherSIM)
	Copy constructor.

Protected Member Functions inherited from XMLInputBase
const tinyxml2::XMLElement *	loadFile (tinyxml2::XMLDocument &doc, const char *fileName, bool verbose=false)
	Loads an XML input file into a tinyxml2::XMLDocument object.

virtual const char **	getPrioritizedTags () const
	Returns a list of prioritized XML-tags.

Protected Attributes
bool	dumpLog
	Set to true, to print out dump time levels.

TimeStep	tp
	Time stepping information.

HDF5Restart *	restartAdm
	Administrator for restart output.

ProcessAdm *	restartProcAdm
	Process admin used for restart output.

int	startRstLevel
	Initial time level for the restart output.

Protected Attributes inherited from SIMSolverStat< T1 >
T1 &	S1
	The actual solver.

DataExporter *	exporter
	Administrator for result output to HDF5 file.

int	startExpLevel
	Initial time level for the DataExporter.

Protected Attributes inherited from SIMadmin
ProcessAdm	adm
	Parallel administrator.

int	myPid
	Processor ID in parallel simulations.

int	nProc
	Number of processors in parallel simulations.

std::string	myHeading
	Heading written before reading the input file.

Private Attributes
bool	saveDivergedSol
	If true, save also the diverged solution to VTF.

Additional Inherited Members
Public Attributes inherited from SIMadmin
SIMoptions &	opt
	Simulation control parameters.

Static Public Attributes inherited from SIMadmin
static int	msgLevel = 2
	Controls the console output amount during solving.

Protected Types inherited from SIMadmin
using	IntVec = std::vector< int >
	Convenience alias.

Detailed Description

template<class T1>
class SIMSolver< T1 >

Template class for transient simulator drivers.

This template can be instantiated over any type implementing the ISolver interface. It provides a time stepping loop and restart in addition.

Member Function Documentation

◆ deSerialize()

template<class T1 >

virtual bool SIMSolver< T1 >::deSerialize ( const HDF5Restart::SerializeData & data )

inlinevirtual

Set internal state from a serialized state.

Parameters

[in] data Container for serialized data

References TimeStep::deSerialize(), SIMSolverStat< T1 >::S1, and SIMSolver< T1 >::tp.

Referenced by SIMSolver< T1 >::restart().

◆ handleDataOutput()

template<class T1 >

void SIMSolver< T1 >::handleDataOutput	(	const std::string &	hdf5file,
		const ProcessAdm &	modelAdm,
		int	saveInterval = `1`,
		int	restartInterval = `0`
	)

inline

Handles application data output.

Parameters

[in]	hdf5file	The file to save to
[in]	modelAdm	Process administrator to use
[in]	saveInterval	The stride in the output file
[in]	restartInterval	The stride in the restart file

References SIMadmin::adm, ProcessAdm::dd, ProcessAdm::getProcId(), SIMSolverStat< T1 >::handleDataOutput(), DomainDecomposition::isPartitioned(), SIMSolver< T1 >::restartAdm, SIMSolver< T1 >::restartProcAdm, and SIMSolver< T1 >::startRstLevel.

◆ parse() [1/2]

template<class T1 >

virtual bool SIMSolver< T1 >::parse	(	char *	keyw,
		std::istream &	is
	)

inlineprotectedvirtual

Parses a data section from an input stream.

Reimplemented from SIMadmin.

References TimeStep::parse(), and SIMSolver< T1 >::tp.

Referenced by SIMSolverTS< T1 >::parse().

◆ parse() [2/2]

template<class T1 >

virtual bool SIMSolver< T1 >::parse ( const tinyxml2::XMLElement * elem )

inlineprotectedvirtual

Parses a data section from an XML element.

Reimplemented from SIMadmin.

Reimplemented in SIMSolverTS< T1 >.

References SIMSolver< T1 >::dumpLog, TimeStep::parse(), SIMSolver< T1 >::saveDivergedSol, and SIMSolver< T1 >::tp.

◆ read()

template<class T1 >

virtual bool SIMSolver< T1 >::read ( const char * file )

inlinevirtual

Reads solver data from the specified input file.

Reimplemented from SIMSolverStat< T1 >.

Reimplemented in SIMSolverTS< T1 >.

References SIMadmin::read().

◆ restart()

template<class T1 >

int SIMSolver< T1 >::restart	(	const std::string &	restartFile,
		int	restartStep
	)

inline

Handles application restarts by reading a serialized solver state.

Parameters

[in]	restartFile	File to read restart state from
[in]	restartStep	Index of the time level to read restart state for

Returns: One-based time level index of the restart state read. If zero, no restart specified. If negative, read failure.

References SIMadmin::adm, IFEM::cout, ProcessAdm::dd, SIMSolver< T1 >::deSerialize(), DomainDecomposition::isPartitioned(), SIMSolverStat< T1 >::S1, and SIMSolver< T1 >::startRstLevel.

◆ serialize()

template<class T1 >

virtual bool SIMSolver< T1 >::serialize ( HDF5Restart::SerializeData & data )

inlinevirtual

Serialize internal state for restarting purposes.

Parameters

data	Container for serialized data

Reimplemented in SIMSolverTS< T1 >.

References SIMSolverStat< T1 >::S1, TimeStep::serialize(), and SIMSolver< T1 >::tp.

Referenced by SIMSolver< T1 >::saveState(), and SIMSolverTS< T1 >::serialize().

◆ solveProblem()

template<class T1 >

virtual int SIMSolver< T1 >::solveProblem	(	char *	infile,
		const char *	heading = `nullptr`
	)

inlinevirtual

Solves the problem up to the final time.

Reimplemented from SIMSolverStat< T1 >.

Reimplemented in SIMSolverTS< T1 >.

References SIMSolver< T1 >::advanceStep(), TimeStep::multiSteps(), IFEM::pollControllerFifo(), SIMSolverStat< T1 >::printHeading(), SIMSolverStat< T1 >::S1, SIMSolver< T1 >::saveDivergedSol, SIMSolver< T1 >::saveState(), and SIMSolver< T1 >::tp.

The documentation for this class was generated from the following file:

/home/runner/work/IFEM-2/IFEM-2/Apps/Utils/SIMSolver.h
