Implementation of basis function cache. More...

#include <ASMs3D.h>

Inheritance diagram for ASMs3D::BasisFunctionCache:

[legend]

Collaboration diagram for ASMs3D::BasisFunctionCache:

[legend]

Public Member Functions
	BasisFunctionCache (const ASMs3D &pch)
	The constructor initializes the class.

	BasisFunctionCache (const BasisFunctionCache &cache, int b)
	Constructor reusing quadrature info from another instance.

const std::array< size_t, 3 > &	noElms () const
	Returns number of elements in each direction.

Public Member Functions inherited from BasisFunctionCache< 3 >
	BasisFunctionCache ()
	Default constructor.

	BasisFunctionCache (const BasisFunctionCache &rhs)
	Copy-constructor.

virtual	~BasisFunctionCache ()=default
	Empty destructor.

void	clear ()
	Clears the basis function cache.

bool	init (int nd)
	Initialize the basis function cache according to policy.

const BasisFunctionVals &	getVals (size_t el, size_t gp, bool reduced=false)
	Obtain basis function values/derivatives in an integration point.

void	setIntegrand (const Integrand *itg)
	Defines the integrand to be used.

const std::array< int, Dim > &	nGauss (bool reduced=false)
	Returns number of integration points.

const std::array< const double *, Dim > &	weight (bool reduced=false) const
	Return integration scheme weights.

const std::array< const double *, Dim > &	coord (bool reduced=false) const
	Return integration scheme nodes.

bool	hasReduced () const
	Returns whether or not a reduced quadrature is enabled.

virtual double	getParam (int dir, size_t el, size_t gp, bool reduced=false) const
	Obtain a single integration point parameter.

void	resizeThreadBuffers ()
	Called if application changes number of threads.

Protected Member Functions
bool	internalInit () override
	Implementation specific initialization.

BasisFunctionVals	calculatePt (size_t el, size_t gp, bool reduced) const override
	Calculates basis function info in a single integration point.

void	calculateAll () override
	Calculates basis function info in all integration points.

size_t	index (size_t el, size_t gp, bool reduced) const override
	Returns global integration point index.

virtual void	setupParameters ()
	Sets up integration point parameters.

bool	setupQuadrature ()
	Configures the quadratures.

Protected Member Functions inherited from BasisFunctionCache< 3 >
std::array< size_t, Dim >	gpIndex (size_t gp, bool reduced) const
	Obtain structured integration point indices.

Protected Attributes
const ASMs3D &	patch
	Reference to patch cache is for.

std::array< size_t, 3 >	nel {}
	Number of elements in each direction.

Protected Attributes inherited from BasisFunctionCache< 3 >
std::vector< BasisFunctionVals >	values
	Cache for main quadrature.

std::vector< BasisFunctionVals >	valuesRed
	Cache for reduced quadrature.

const Integrand *	integrand
	Integrand to use.

int	nderiv
	Number of derivatives.

std::shared_ptr< Quadrature >	mainQ
	Main quadrature information.

std::shared_ptr< Quadrature >	reducedQ
	Reduced quadrature information.

size_t	nTotal
	Total number of main integration points.

size_t	nTotalRed
	Total number of reduced integration points.

Private Member Functions
std::array< size_t, 3 >	elmIndex (size_t el) const
	Returns structured element indices for an element.

Additional Inherited Members
Public Attributes inherited from BasisFunctionCache< 3 >
int	basis
	Basis to use.

Detailed Description

Implementation of basis function cache.

Constructor & Destructor Documentation

ASMs3D::BasisFunctionCache::BasisFunctionCache ( const ASMs3D & pch )

The constructor initializes the class.

Parameters

[in] pch Patch the cache is for

ASMs3D::BasisFunctionCache::BasisFunctionCache	(	const BasisFunctionCache &	cache,
		int	b
	)

Constructor reusing quadrature info from another instance.

Parameters

[in]	cache	Instance holding quadrature information
[in]	b	Basis to use

void ASMs3D::BasisFunctionCache::calculateAll ( )

overrideprotectedvirtual

Calculates basis function info in all integration points.

BasisFunctionVals ASMs3D::BasisFunctionCache::calculatePt	(	size_t	el,
		size_t	gp,
		bool	reduced
	)		const

overrideprotectedvirtual

Calculates basis function info in a single integration point.

Parameters

[in]	el	Element of integration point (0-indexed)
[in]	gp	Integration point on element (0-indexed)
[in]	reduced	If true, calculate for reduced integration scheme
